PWS 8-M Water Distiller
Description
(8-M shown with optional 3.0 US Gal. Holding Tank. The 3.0 US Gal. Holding Tank must be purchased separately)
When manually filled, this distiller will produce approximately one gallon of pure water. Following each distillation cycle the distiller will automatically shut off until water again is poured in the boiling chamber.
Designed with the largest lid opening in the industry and a ‘V’ bottom boiler for easy cleaning, your distiller is easier to maintain than others on the market. This Distiller features high quality power and fan switches as well as a reliable float switch that shuts off the distiller when the water level is low, protecting the heating element from burning out.
Source water is placed into the boiling chamber and brought to a boiling point. Pure steam rises to the top of the distiller and enters a baffle system, which draws steam toward a finned cooling coil system. As the steam enters the cooling coil, a gas vent releases any volatile gases from the coil. Following condensing, this hot steam becomes pure water which runs through a charcoal filter and is stored in a stainless steel tank.
Features & Benefits:
• Trouble free float system
• Seal protected switching
• Highly efficient, stainless steel finned coil
• Large 5″ boiling and storage tank opening
• 1/2” impurities drain
• Stainless steel post charcoal filter
Warranty:
• 2 year parts
• 15 year pro rated on stainless steel
• Countertop unit
• Manual fill unit
Height: 13 1/2” (34.3cm)
Depth: 10 5/8” (27.0cm)
Width: 17 1/4” (43.8cm)
Weight: 24 lb (11.0kg)
(without tank)
Volts: 120v
Amps: 9.2
Hertz: 60
Watts: 1100
Volts: 220v
Amps: 5.0
Hertz: 50/60
Watts: 1100
Distilling Capacity: 8.0 US gal (30.0 L)/24 hrs
Holding Tank Capacity: 3.0 US gal (11.0 L)
Shipping Weight: 30.0 lb (13.5 kg)
Optional Holding Tank: 10.0 lb (4.54 kg)
